It’s not the operating systems we are working with, that’s for sure. Take for example the European Space Agency (ESA)’s recently-launched Solar Orbiter. Since the spacecraft will get close to the Sun, it will have to withstand harsh solar conditions. The Solar Orbiter then needs an operating system that can operate under specific conditions. The ESA developed a real-time operating system (RTOS) for Solar Orbiter that can react to dangerous situations in 50 seconds:
"We’ve got extremely demanding requirements for this mission," says Maria Hernek, head of flight software systems section at ESA. "Typically, rebooting the platform such as this takes roughly 40 seconds. Here, we’ve had 50 seconds total to find the issue, have it isolated, have the system operational again, and take recovery action.”
To reiterate: this operating system, located far away in space, needs to remotely reboot and recover in 50 seconds. Otherwise, the Solar Orbiter is getting fried.
The criteria by which we judge Windows or macOS are fairly simple. They perform a computation, and if the result of this computation is correct, then a task is considered to be done correctly. Operating systems used in space add at least one more central criterion: a computation needs to be done correctly within a strictly specified deadline. When a deadline is not met, the task is considered failed and terminated. And in spaceflight, a missed deadline quite often means your spacecraft has already turned into a fireball or strayed into an incorrect orbit. There’s no point in processing such tasks any further; things must adhere to a very precise clock.
The time, as measured by the clock, is divided into singular ticks. To simplify it, space operating systems are typically designed in such a way that each task is performed within a set number of allocated ticks. It can take three ticks to upload data from sensors; four further ticks are devoted to fire up engines and so on. Each possible task is assigned a specific priority, so a higher-priority task can take precedence over the lower-priority task. And this way, a software designer knows exactly which task is going to be performed in any given scenario and how much time it is going to take to get it done.
Image via Ars Technica
